Specifications

Specification

Drive System	48V/450A Advanced EV AC Controller, 5kW AC Motor
Charger	Pro Charging Systems Onboard Charger
Capacity	3 Passengers + Stretcher

Body Configuration

Windshield	Folding DOT Windshield
Roof	Aluminum Frame + PP Injection Molded
Floor	Aluminum Profile Non-Slip Floor, High Strength Structure, Corrosion Resistant, Aging Resistant
Mirrors	Adjustable & Foldable Side Mirrors
Lights & Warning Signals	Hi/Lo Beam Positioning LED Headlights, Daytime Running Lights, LED Taillights, Brake Lights, Snail Horn & Reversing Buzzer
Safety	Retractable Seat Belts
Dash	Molded Instrument Panel, Digital Speedometer, Headlight/Turn Signal/Horn, Combination Switch, FNR Switch, Cup Holders, Double USB 12V Power Supply, State of Charge Meter
Steering	Double-Ended Rack And Pinion, Self-Adjusting
Braking System	4 Wheel Hydraulic Disc Brake + Electromagnetic Parking Brake
Front Suspension	Double A-Frame Independent Front Suspension + HD Coil Spring Over HD Hydraulic Shock Absorbers
Rear Suspension	Split Case Transaxle, Gear Ratio 16:1, HD Coil Spring Over HD Hydraulic Schock Absorbers + Rear Suspension Stabilizing Bar
Tires	205/65-10" Aluminum Alloy Wheels

Dimensions and Performance

Overall	LxWxH: 11'10"L x 3'11.6"W x 6.47'H approx
Max Speed	19 mph
Box Loading Capacity	892 lbs

Electrical Systems

Controller	AdvancedEV Controller 450AMP
Motor	AC Motor 48V/5KW
Charger	Pro Charging Systems Onboard Charger 48V/15A
Battery	US8VGCXC Batteries AdvancedLi Lithium Battery Pack 51.02v/150AH

Upgrades

Windshield	DOT Rated With Toughened Glass
Battery	Advanced Li Battery AGM Sealed Lead Acid
Multi Media	Wet Sounds® Stealth 6 Soundbar Wet Sounds® Stealth 10 Soundbar Wet Sounds® Subwoofer
Other Upgrades	Custom Key Upgrade

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
